Southtech Cross-bending Tempered Glass Production Machine (Glass Bending Furnace)

Southtech Cross Curved Bending Tempered Glass Production Machine(glass bending furnace)(HWG series)1, Advanced Processing Methods Of CNC Guarantee The Accuracy Of Bending ;2, It Spends Less Time On The Adjustment For The Use Of The Simple And Convenient Computer Adjust Arc Structure ;3, The Distinctive Press-Roller Structur

Featured Products

Southtech Cross Curved Bending Tempered Glass Production Machine(glass bending furnace)(HWG series)

Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)


1, Advanced Processing Methods Of CNC Guarantee The Accuracy Of Bending ;

2, It Spends Less Time On The Adjustment For The Use Of The Simple And Convenient Computer Adjust Arc Structure ;

3, The Distinctive Press-Roller Structure Can Reduce The Straight Length Of Both Ends Of The Curve ;

4, It Can Produce Flat Tempering Glass With Cross Bending And Cooling Secton ;

5, Technical Parameters
ModeMax.Loading SizeMin.SizeRadiusThicknessm2/hInstalled
Capacity
HWG0306350curved×600250curved×100250/5003.2-645≥250kva
HWG0509500curved×900280curved×100300/5003.2-645≥350kva
HWG0812800curved×1250350curved×200400/10003.2-828≥420kva
HWG10151000curved×1500380curved×200450/20004-1228≥480kva
HWG10201000curved×2000380curved×380480/20004-1228≥450kva

6, Mainly In: Domestic Appliances, Furniture, Lamp, Automotive Sidelites, Interior Decorations, Shower Tooths, Etc.

Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)

7, Machine details

Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)

Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)

Reasons to choose SOUTHTECH

Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)

Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)

Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)

After sales service

Southtech Cross Curved Bending Tempered Glass Production Machine (glass bending furnace)

1. We supply with our machine a sufficient quantity of spare parts that could be enough up to 5 years. And we have spare-parts warehouse in our different regional offices around the world.
2. Available a 24 hour hot-line service, and most important, we can connect to your machine on-line, and on our new mobile application service.
3. We offer a yearly maintenance contract for all clients who are interested.


Conclusion:
We deliver a customized and tailor-made machine. We also offer standard machines.
Others can say or claim whatever they want. But at Southtech, YOU SEE, and You can believe. Performance is irrelevant to complications.
We have a machine that will help you grow your business.
